Upright Wheels Q - Z


Click on a little photograph to see it full size


Romney wheel Romney wheels were manufactured by Business Products (N.Z.) Ltd, a one-man business founded and owned by an immigrant from the Netherlands, Jan Boersma. He designed and produced them himself until 1978 when he returned with his family to his homeland. It's said that he lived in Wellington and worked for stock-and-station company Wrightsons, but this is not confirmed.

Romneys were supplied either as a kitset or assembled. They are made of NZ native beech and kauri, and finished with a mahogany stain. The one-speed whorl is metal.


Schofield wheel George Henry Schofield was a builder living in Wadestown (a hillside suburb of Wellington) from the 1930s till at least 1946. After that he retired and moved with his wife Rosamond to Titirangi, Auckland. Mrs Schofield was an early member of the New Zealand Guild of Spinners, Dyers and Weavers, and in their February 1938 newsletter she was particularly commended for her wonderful teaching at the Technical School, Wellington.

Another Schofield wheelThe first wheel pictured is said to have been made, in oak, by Mr Schofield for his wife. It was later gifted by Dorothea Turner to the Auckland Museum. Others were made of cheaper materials for use in schools and technical colleges (there is even an old newspaper clipping showing one in use by a student in Indonesia) and the wheel in the second photograph was probably one of these. It is very light and easy to carry, and only the flyer and wheel hub are oak; the rest is southern beech.

Tension system of Schofield wheel The curved metal strip, called a flyer frame, holds the spindle and pivots at the support posts. At its left-hand end a cord is attached at a hole in the metal. This cord passes over or under the bobbin groove. (I have set it to pass under, as this is the way one held by the Auckland War Memorial Museum is set up, but either way should give about the same contact with the groove.) Then it goes through a notch in the right-hand end of the frame, and down to attach to a spring and a threaded metal rod which are fastened to a bracket behind the front post. By tightening a small nut at the bottom of the rod, the frame is tilted and both the drive wheel tension and the bobbin tension are adjusted.

However, tightening the drive wheel tension to an acceptable level made the bobbin tension impossibly tight. This was resolved by adding a tight cord between an otherwise inexplicable notch in the flyer frame and a little eyelet hook in the right front post, which tightens the drive wheel tension separately.

Schofield wheel in use in the US Schofield wheels were also the prototype for another wheel produced in large numbers for schools, the McDonald wheel. The flyer frame idea was also taken up by Philip Poore in the Wendy.

Recently I have learned of a Schofield in the US, which its owner uses and much prefers to a more modern wheel (picture at right). She has found that it works equally well with double drive and no scotch tension string. It was brought to the US by a returning tourist, who had found it hanging dusty and unused in the rafters of a school somewhere in New Zealand.

Ashford ScholarAshford Scholar Mark 1

The Scholar was first made by Ashford in 1984. Scholar Mark 1 (on the left) continued in production until 1987, when Scholar Mark 2 (on the right) was introduced. From 1997 it was superseded by the Kiwi, but there are still many in use.

SerenaSerena

Serena wheels by Sleeping Beauty were supplied unfinished as a kitset and were designed by Alex Baillie as a more basic economy model. Though simpler in construction, with the footman passing through the table, they share with Thumbelina the small table and widely splayed legs.
More on Sleeping Beauty wheels

Wheel by Ron ShearmanWheel by Ron Shearman
Ron Shearman, of Marton in the North Island, began his career as a chairmaker and then a cabinetmaker, and later became a teacher of woodwork, engineering and technical drawing. He made his first wheel about 40 years ago. He says each takes around 100 hours of work. After experimenting with several designs he made about 40 of the first wheel shown.

The second wheel is the result of many refinements and improvements, and is made mostly of macrocarpa.

Another Shearman wheelHe has also made a few with finials, extra pieces of turned wood inside the rim of the wheel between the spokes. These are uncommon in New Zealand-made wheels. They are not just for decoration; the extra mass of the rim of the wheel helps to preserve the momentum and make spinning for long periods less tiring. The third wheel shown is made of elm except for the flyer and bobbins which are tawa. It can be used with either double drive or scotch tension. I am sometimes asked what is my own favourite wheel - this is it.

Wheel by Ces Shields

Cecil ("Ces") Shields of Heathcote, Christchurch, began making spinning wheels in 1969, and by 1977 he had made and sold 192. The drive band was a twisted bootlace, and the weights in the wheel were made of lead from batteries, melted into round plugs.Ces Shields and his square wheel

He made several versions of his wheel. The second photograph shows him spinning on a square wheel he made in 1977. He also made carders and other spinning equipment. He died in 1979.

Simplex by BaynesSimplex by Baynes
Simplex wheels were made by Baynes; like other Baynes wheels they have whorl built in to the flyer, and a hole through it for the yarn to pass through. Like the rest of the wheel, though, it is more economically constructed than the familiar Baynes Colonial, using a lot of plywood.
More on Baynes wheels

Smithies wheelanother Smithies wheel
Harold Smithies (1911-2006) of Invercargill worked in the construction industry, and was very conversant with all kinds of metal framing. On his retirement in 1976 he began to make spinning wheels, using wheels of treadle sewing machines he found at the dump but making the remainder of the mechanism himself. His records show that he made 90 in all. The height of the post (and thereby also the drive band tension and orifice height) is adjustable.


Bob Spence was from Shetland but lived in New Zealand for almost 40 years.
Wheel by Bob SpenceIn the 1970s he made several spinning wheels, including this one which was made specially for Margaret Stove. His wheels are copied from the Shetland "spinnie" but made of New Zealand native woods. This double drive wheel is specially designed for fine spinning. Mabel Ross (Encyclopedia of Hand Spinning 159) writes of Shetland wheels designed for gossamer thread "the diameters of spindle and bobbin whorls differ only very slightly... This produces the necessary high twisting rate with very slow draw-on, useless for normal threads..."

Sprite wheelSprite wheelSprite wheel
Sprite was an experimental model made by Philip Poore in small numbers in the last few years that he made Pipy wheels. They have a similar two-legged stance to the Wendy, but the drive wheel is metal, there is no flyer frame and they stand a little taller. They bear under the treadle the code MD - this one is MD7108, probably made in August 1971.
More on Pipy wheels

Two Sutherland wheelsSutherland wheelAnother Sutherland wheel
Alec Sutherland of Atawhai, Nelson started making wheels in the 1970s to early 80s, getting some of his wood from the nearby Wakapuaka tip. The spindle and flyer just sit on top of two grooved pieces of leather attached to the maidens. There is some variation in Sutherland wheels: the larger one in the third picture has different turnings, whereas the smaller is only 73cm tall (the others are all 81cm). All have 4 legs, the back two close together.

Early Suzie by Majacraft
The earlier Suzie by Majacraft does not fold, and there have been several other changes.
More on Majacraft wheels

Thompson wheelThompson wheel John Thompson of Christchurch is said to have made two wheels a year in the 1970s and 1980s. Both the wheels illustrated are mahogany and have a metal plate inscribed "J. Thompson Christchurch NZ". The first has a single balance weight inset into the drive wheel. The one on the right has differently set up maidens and spindle bearings. It may be later, with its crisp, deep turnings: Mike Keeves comments "To me this indicates more confidence and competence as experience has been gained over time".

ThumbelinaThumbelina These Thumbelinas were made by Baillie and Watts under the name Sleeping Beauty, probably in the 1970s. The mother-of-all is hinged to adjust the distance from the drive wheel. The bar that supports the treadle is attached to the front legs by a metal hook-and-eye.

The second picture (of a different wheel) shows the little lever at the back of the mother-of-all. It is turned to the side to release the back maiden for removing the spindle to change bobbins. The flywheel is made of a composite wood.

Thumbelina by Omana Industries Later Thumbelinas were considerably re-designed. One bought in 1978 - the instructions with it say "Thumbelina Mark 2 (1978)" - is almost identical to the ones shown here except that it has no label, and a screw-and-spring joining the treadle to the footman. The drive wheel is now solid wood, the turning is more elaborate, the mother-of-all is a different shape and the legs are not so splayed. The little pedestal on top of the table has gone. It seems that Baillie and Watts redesigned the Thumbelina at this time. Thumbelina by Omana Industries

However, the shape of the treadle, the groove(s) around the face of the wheel, and the orifice passing through the front maiden are all the same as the earlier Thumbelina. The two wheels pictured here are probably by Omana Industries, as they are identical with the one shown in their leaflet, even down to the metal plate on the front which says "Sleeping Beauty/a craft product/made in New Zealand".

The original information that would have come with an earlier Thumbelina wheel can be downloaded here.
More on Sleeping Beauty wheels

Tiny Tim by Majacraft
Tiny Tim is a Majacraft wheel, now superseded by their Little Gem. Made of native rimu timber, it folds easily and has a nicely made carrying handle.

Tiny Tim folded The wheel shown here has been adapted by reversing the flyer head so that it is more to the right. Some Tiny Tims have a plainer flywheel, without the deep grooves, and some do not have the built in kate.
More on Majacraft and their wheels

Tom Thumb foldedTom Thumb
The first Tom Thumb shown is unmarked but another is known which has "Tom Thumb - Handmade from New Zealand Kauri" lightly carved in the underside of the treadle. It can be used with either double drive or scotch tension, and spins well. The mother-of-all can be folded over for travelling. These wheels were made in the 1980s by Albie Thomas out of recycled kauri from the old tram barn in Manukau Road, Auckland.

Early Ashford Traveller

Traveller wheels by Ashford originally looked like this one. They were made from 1977 to 1979.

Tui wheel
Tui wheels were developed by Mr K. Fomotor as a simpler version of the Peacock. The flyer arms are more curved than other Peacock wheels, the post supporting the mother-of-all is in front of the wheel not behind and the sleeve by which its height is adjusted is plastic instead of metal. The footman passes through a hole in the table.
More on Peacock wheels

Tyler upright C.A. Tyler made little upright wheels like this one dated 1969, which is named "Carmela", as well as large saxony and double table (norwegian-style) wheels.

He also made some small wheels which I have had difficulty categorising. They will be found with the saxonies.
More on Charlie Tyler and his wheels

Ward wheel
Edwin ("Ed") Ward, a retired ships' furniture maker, came to New Zealand about 1970 from Yorkshire, England to take up a position teaching woodwork at Marton District High School. He made about 8 wheels, all of Australian Black Bean timber.


Warr wheel
Reginald Warr of Hawkes Bay made 25 or 30 of these in the 1970s. He used various timbers, including rewarewa like this one, kauri, macrocarpa, tawa and even one of teak. The owner's initials were carved in very big letters on the treadle (the first owner of this wheel was EW) and they are also marked with Mr Warr's name or initials.

Big Warr wheel
He also made about 6 of these big heavy wheels. He made this one for himself, and carved his name on the treadle. In spite of its weight it is easily moved on its built-in wheels.

Weavejoy flyerWeavejoy wheel
Weave-joy Looms of Portobello, Dunedin, produced various looms and a range of wheels in the 1970s. The first one is made mostly of rimu and heavier than it looks. There is no finish on the wood and the carpentry is quite rough, except for the flyer. The maker, Peter Lawrenson ("Cottage Weavers") also sold handspun, handwoven tweeds.

Another Weave-joyThe second Weave-joy shown, which is in Oregon, USA, is better finished, with a brass label, and it has the scotch tension adjustment above the flyer. Its design could have been influenced by Walter Morrison's wheels. The drive wheel and the footman are off an old treadle sewing machine. The uprights, feet and table are fine heavy wood and look as though they might have once been part of an old table or chair. The treadle is ply wood. Bobbins, whorl and metal findings are visibly artisan made. The wheel's new owner finds that with oil and careful adjustment it spins well and likes to make a fine thread.

Wee Peggy Wee Peggy by Rappard was a kitset wheel, and is not very different from the Little Peggies except that the front maiden does not extend above the orifice. This one was bought and assembled in 1978.

The assembly instructions and parts list for a Wee Peggy are here; original parts are no longer available.
Recently Ashford have made a version of the Wee Peggy, though few have been sold in New Zealand. Details here.
More on Rappard and their wheels

WeeQT

The WeeQT was made by Linkwood products in Waimate, South Canterbury. The only clue as to date is that it was advertised in The Web in June 1986. It works on the "direct drive" or "friction drive" principle - there is no drive band, but the edge of the whorl rests against the side of the wheel near the rim and is turned by friction as the wheel turns. WeeQT box

The overall height of the spinning wheel is only 38cm. For transport it can be carried in a little box, with the flyer assembly (which has only one arm) removed and fixed into the box separately.

Wendy by Pipy Craft
Wendy wheels by Philip Poore were designed for easy transport, and can be laid flat in the boot of a car - in fact it is apparently possible for a passenger in a Volkswagen to spin on a Wendy. They have an unusual design with a metal flyer frame that is tilted by a tension screw (inside the wooden ball) that has a left and right hand thread. They were designed for double drive but can be adapted for brake tension or even bobbin lead. This one has the Tekoteko stamp and is signed P.B. Poore.
More on Pipy wheels

Wild wheel
Geoff Wild made about five of these based on the Nagy upright wheel, in Upper Hutt near Wellington, in the early 1980s (after Mr Nagy's departure). The details of turning are different from Nagy's, and the treadle is wider. Unlike Nagy he did not use kauri: this wheel is a mixture of jarrah, rewarewa and rimu.

Wildy: see Carlisle

Wilson wheelPlain Wilson wheel James "Gib" Wilson (1902-1971) of Invercargill made at least half a dozen of these. It is recounted that even in his later life when very ill he "perked up when talking wood turning, or working on the lathe". The two wheels are similar in concept though the second is much more elaborately detailed and it has the flyer and treadle on the other side of the posts. The elaborate one is made of southern beech, the simpler one of a Malayan hardwood called miranti (or meranti). Another elaborate Wilson has been seen in mahogany, without the diagonal struts from posts to base.


Wing wheelWing wheel
Mr Wing of Redcliffs, Christchurch, made quite a few of these in the late 1970s. Most have the plain rectangular table made in four pieces with the wheel let into it, like the first two illustrated. However, one has recently come to light with a table made of two pieces separated by turned spacers - similar to the way the Ashford Traveller is made, but the turning of the spacers is quite different.

Spacer of Wing wheelWing wheelThe first wheel shown here has two maidens and a conventional orifice. The second two have no front maiden, and a hook instead of an orifice.

Wing also made norwegian-style wheels.
More on S.C. Wing and his wheels
